Detailed LDR80K2 Specifications

The technical material below is retained for this model only. Do not transfer a range, pulse, interface, mechanical or safety value from another 1064 nm product.

Specifications

The tables below retain the supplied model record except for entries explicitly withheld after a comparison with the current model PDF. A value, option or condition from another model is not interchangeable. General explanations are separated from model-specific entries.

Source-review note

The source has an incomplete energy unit, time units under a frequency label, differing capability statements and conflicting shock-waveform labels. No missing unit, conversion or qualification outcome is inferred.

Current LDR80K2 document — source checked 13 September 2026. On a small screen, swipe wide tables horizontally to read every column.

LDR80K2 — TECHNICAL SPECIFICATIONS

Laser Wavelength	1064nm±1nm
Pump Mode	Side-pumped semiconductor (diode) pumping
Designation Frequency	Withheld pending a corrected, controlled model specification. See the source-review note above.
Trigger Mode	Internal-Synchronization Illumination / External-Synchronization Illumination (Trigger Delay: 304.0 μs ± 0.1 μs)
Output Energy	Withheld pending a corrected, controlled model specification. See the source-review note above.
Dimensions	≤150×102×55mm
Weight	≤850g
Designation Capability	Withheld pending a corrected, controlled model specification. See the source-review note above.
Q-Switch Type	Electro-optic Q-switch (EO Q-switch)
Pulse Width	15ns ±5ns
Beam Divergence	≤0.15mrad
Energy Instability	≤8%(RMS)
Laser Designation Performance	Short-duration irradiation mode: The irradiation time for each cycle is 17 seconds, followed by a 30-second interval. The system can perform up to 8 consecutive irradiation cycles. Long-duration irradiation mode: The irradiation time for each cycle is 60 seconds, followed by a 45-second interval. The system can perform up to 4 consecutive irradiation cycles.
Optical Axis Parallelism Error Relative to Mounting Datum	≤0.5mrad
Ranging Performance	· Minimum Measuring Distance: ≤ 300 m · Maximum Measuring Distance: ≥ 15 km (under conditions of a 2.3 m × 2.3 m target, diffuse reflectivity ≥ 0.2, visibility ≥ 20 km, and relative humidity ≤ 70%) · Ranging Frequency: 1–20 Hz (up to 3 simultaneous targets) · Ranging Accuracy: ≤ 5 m · Probability of Valid Ranging: ≥ 98% · Continuous Ranging Operating Time: 90 s (20 Hz continuous operation for 90 s, rest time ≤ 5 minutes before continuing ranging)
Communication Serial Interface	RS422
External Synchronization Interface	+5 V differential line driver/receiver, RS-422 interface (delay from external synchronization signal to laser emission: 304.0 μs ± 0.1 μs).
Laser Coding Mode	l Precise Frequency Coding l Time Coding l Pseudo-Random Coding
Period Accuracy	<+-1us
Power Supply	DC 20V ~ 28V
Power Consumption	During operation, the average power consumption is not more than 55W, and the peak power consumption is not more than 100W.
Low-Temperature Test	Operating temperature: −40 °C Storage temperature: −45 °C
High-Temperature Test	Operating temperature: +60 °C Storage temperature: +65 °C
Damp-Heat Test	Relative humidity: 95% ± 3% Temperature: +35 °C ± 2 °C Storage duration: 72 h
Shock Test	Withheld pending a corrected, controlled model specification. See the source-review note above.
Vibration	The equipment shall withstand flight vibration and the shocks occurring during takeoff and landing, and all components shall meet the environmental conditions of vehicle transportation. The vibration profile is a swept-frequency spectrum: l From 5 Hz to 16 Hz, constant-displacement sinusoidal vibration with an amplitude of 1.5 mm; l From 16 Hz to 60 Hz, constant-acceleration sinusoidal vibration with an acceleration level of 1.5 g. Each of the three axes shall be vibrated for 36 minutes. Test condition: The product shall be mounted on the vibration table in its normal operating configuration and powered on during the test. Post-test requirement: After vibration testing, the equipment shall operate normally.

LDR80K2 — PIN INTERFACE

J30J-21ZKP
pinout	functionality	clarification	orientations	note
1	TX+	RS422 +	exports	RS422 communication interface
2	TX-	RS422 send -	exports
3	RX+	RS422 Receive +	importation
4	RX-	RS422 Receive -	importation
5	GND	RS422 Ground	GND
6	EN+	power supply enable (computing)		24V power supply enable switch
7	EN-	power supply enable (computing)
8-13		unoccupied
14	A	External Synchronous Differential+ (A)	importation	A, B are the A and B outputs of the differential chip (RS422 chip)
15	B	External Synchronous Differential - (B)	importation
16	LED+	DC5V	importation	Indicator light power supply
17	LED-	GND	importation
18-21

LDR80K2 — PIN INTERFACE

J30J-04ZK
Pinout	functionality	clarification	orientations	note
A, B	24V	Power supply	importation	bonus
C, D	GND	electric place	importation	(loanword) hack (computing)

Technical drawings

LDR80K2 — OUTLINE DIMENSION(mm)

Detailed LDR60K1 Specifications

The technical material below is retained for this model only. Do not transfer a range, pulse, interface, mechanical or safety value from another 1064 nm product.

Specifications

The tables below retain the supplied model record except for entries explicitly withheld after a comparison with the current model PDF. A value, option or condition from another model is not interchangeable. General explanations are separated from model-specific entries.

Source-review note

The old range and code-accuracy summary contains qualifiers that are not established by the current model document. Those entries are withheld pending confirmation.

Current LDR60K1 document — source checked 13 September 2026. On a small screen, swipe wide tables horizontally to read every column.

LDR60K1 — Technical Specifications

Operating modes	Ranging, designation
Pump source	Diode array
Operating wavelength	1064 nm ± 3 nm
Pulse energy	≥ 60 mJ
Pulse energy stability	Within a single designation cycle, single-pulse energy deviation ≤ ±10% of mean energy (after 2 s of emission)
Beam divergence	≤ 0.3 mrad
Pulse width	15 ns ± 5 ns
Laser optical-axis stability	≤ 0.05 mrad
Optical-axis parallelism error	≤ 0.3 mrad (relative to mounting datum)
Ranging performance
Ranging frequency	1 Hz / 5 Hz / single-shot
Continuous ranging	1 Hz: ≥ 10 min; 5 Hz: ≥ 5 min
Measurement range	Withheld pending a corrected, controlled model specification. See the source-review note above.
Ranging accuracy	±2 m
Detection rate	≥ 98%
Dimensions	≤ 116 mm × 52 mm × 96 mm
Weight	≤ 680 g
Designation performance
Laser code accuracy	Withheld pending a corrected, controlled model specification. See the source-review note above.
Designation frequency	20 Hz fundamental (supports precise frequency coding)
Service life	≥ 1,000,000 pulses
Environmental Adaptability
Operating temp	–40°C to +55°C
Storage temp	–45°C to +65°C

Technical drawings

LDR60K1 — OUTLINE DIMENSION

Detailed LDR80K1 Specifications

The technical material below is retained for this model only. Do not transfer a range, pulse, interface, mechanical or safety value from another 1064 nm product.

Specifications

The tables below retain the supplied model record except for entries explicitly withheld after a comparison with the current model PDF. A value, option or condition from another model is not interchangeable. General explanations are separated from model-specific entries.

Current LDR80K1 document — source checked 13 September 2026. On a small screen, swipe wide tables horizontally to read every column.

LDR80K1 — Technical Specifications

Parameter	Specification
Wavelength	1064 nm
Range (Ranging)	≥ 10,000 m
Weight	≤ 680 g
Dimensions	116 mm × 52 mm × 96 mm

LDR80K1 — TECHNICAL SPECIFICATIONS

Operating modes	Ranging and laser designation
Pump source	Laser diode array
Operating wavelength	1.064 μm
Average energy per designation cycle	Average single-pulse energy per designation cycle ≥ 80 mJ
Pulse energy fluctuation	Within one designation cycle, the single-pulse energy variation shall not exceed 10% of the average energy (over the full temperature range, with statistics taken 2 s after laser emission starts).
Beam divergence	≤ 0.30 mrad
Pulse width	15 ns ± 5 ns
Optical axis parallelism error	Parallelism error between the optical axis and the mounting reference: ≤ 0.5 mrad.
Ranging performance	Minimum measuring distance: ≤ 300 m Maximum measuring distance: ≥ 10 km(for a 2.3 m × 2.3 m target with diffuse reflectance ≥ 0.2, visibility ≥ 23 km, and relative humidity ≤ 70%) Ranging rates: 1 Hz, 5 Hz, single-shot Ranging accuracy: ≤ 5 m Probability of correct ranging: ≥ 98% Continuous ranging operating time: 5 min(At 5 Hz: continuous operation for 5 min, rest time ≤ 3 min, then ranging can be continued.)
Laser designation performance	Nominal designation repetition rate (for verification): 20 pps Short designation mode: each cycle has 17 s of designation time and 30 s interval; up to 8 consecutive cycles Long designation mode: each cycle has 60 s of designation time and 45 s interval; up to 4 consecutive cycles After completing one long and one short designation cycle, the interval before the next designation shall be within 30 minutes.
Laser coding	Meets the weapon system coding requirements and provides user-programmable code expansion capability. Supports external synchronization input; the external signal can control the laser emission pattern for coding. Coding method: precise frequency code (eight groups of pre-stored period-code patterns). Coding accuracy: ≤ 2.5 μs.
Dimensions	≤ 116 mm × 52 mm × 96 mm
Weight	≤ 680 g
Electrical characteristics	Input voltage: DC 18 V to 32 V The electrical and electronic components inside the laser rangefinder/designator are compatible with the system power characteristics. Average power: ≤ 80 W; peak power: ≤ 120 W After PCB design and debugging are completed, all circuit boards are coated with conformal coating to provide moisture, salt-spray and fungus protection.
External power input requirements	When sharing the same power supply with motor or other inductive loads, the laser rangefinder/designator should use a soft-start (3–5 s). At the instant of sudden power-on, the induced voltage generated by motors and other inductive loads at the module input may be several times the nominal input voltage, which can cause over-voltage damage. During power-up, it is recommended to use the dedicated power-on control function of the laser rangefinder/designator to stagger its power-on time from other loads. After other loads have powered up and stabilized, then enable power to the rangefinder/designator. The power input of the laser rangefinder/designator should be isolated from other inductive loads. If conditions allow, a DC filter (30 V / 10 A) can be added at the module’s power input. The power supply for the laser rangefinder/designator shall satisfy the peak power demand. When testing the module alone, with a DC supply voltage of 24 V, the supply current should be greater than 6 A. If the output voltage is lower, the rated output current of the supply should be increased accordingly.
Temperature Requirements	High-Temperature Requirements Operating temperature: ≤ +55 °C Storage temperature: ≤ +65 °C Low-Temperature Requirements Operating temperature: ≥ −40 °C Storage temperature: ≥ −45 °C
Vibration Requirements	The equipment shall withstand flight-induced vibration and shocks occurring during takeoff and landing. All components shall also meet the environmental conditions of vehicle transport. Vibration spectrum: From 15 Hz to 33 Hz, constant-displacement sinusoidal vibration with amplitude 0.91 mm; From 33 Hz to 700 Hz, constant-acceleration sinusoidal vibration with amplitude 2 g. Duration: 1 hour per axis in three orthogonal directions (X, Y, Z). Test conditions: The product shall be mounted on the vibration platform in its normal operating configuration and powered on during testing. After vibration testing, the equipment shall operate normally.
Shock Requirements	Vertical axis: ≥ 10 g Lateral axis: ≥ 10 g Longitudinal axis: ≥ 10 g Shock waveform: post-peak sawtooth, duration 11 ms; applied along X, Y, and Z axes, both directions on each axis, 18 shocks in total. Test conditions: The product shall be mounted on the shock test platform in its normal operating configuration and powered on during testing. After shock testing, the equipment shall operate normally.

LDR80K1 — Electrical Interface

Pin No.	Signal Definition	Input/Output	Description	Remarks
1.	+28V	Input	The power supply characteristics comply with the relevant requirements of MIL-STD-810G.	Power Supply
2.	+28V
3.	+28V
4.	+28V_GND
5.	+28V_GND
6.	+28V_GND
7.	Power-On Control (+)	Input/Output	Refer to the requirements specified in the Power-On Control section.	I/O Control
8.	Power-On Control (-)
9.	RS422_RX+	Input/Output	The logic level and drive capability comply with the RS-422 interface standard. Characteristic impedance: 120 Ω.	The transmit/receive pin definitions correspond to the laser rangefinder itself.
10.	RS422_RX-
11.	RS422_TX+
12.	RS422_TX-
13.	RS422_GND
14.	External Synchronization Control Signal	Input	The logic level and drive capability comply with the RS-422 interface standard.	External synchronization signal used to control laser coding.
15.	External Synchronization Control Signal (–)

Technical drawings

LDR80K1 — OUTLINE DIMENSION(mm)

Detailed LDR40K1 Specifications

The technical material below is retained for this model only. Do not transfer a range, pulse, interface, mechanical or safety value from another 1064 nm product.

Detailed LDR40K3 Specifications

The technical material below is retained for this model only. Do not transfer a range, pulse, interface, mechanical or safety value from another 1064 nm product.

Specifications

The tables below retain the supplied model record except for entries explicitly withheld after a comparison with the current model PDF. A value, option or condition from another model is not interchangeable. General explanations are separated from model-specific entries.

Source-review note

The current document gives different temperature conditions in its active-mode and environmental sections. This page does not combine them into a broader operating guarantee.

Current LDR40K3 document — source checked 13 September 2026. On a small screen, swipe wide tables horizontally to read every column.

LDR40K3 — TECHNICAL SPECIFICATIONS

Parameter	Specification
Wavelength	1064 nm
Range (Ranging)	≥ 5,000 m
Range (Designation)	≥ 3.5 km
Weight	≤ 420 g
Dimensions	95 mm × 97 mm × 48 mm

LDR40K3 — Electrical Interface Requirements

Pin No.	Label	Description / Remarks
P-1	VIN+	26 V ± 4 V power input
P-2	VIN+	26 V ± 4 V power input
P-3	T+	External sync signal (positive)
P-4	VDD	For programming use
P-5	GND	For programming use (ground)
P-6	ARM_SWCLK	Programming clock (SWD interface)
P-7	ARM_SWDAT	Programming data (SWD interface)
P-8	T–	External sync signal (negative)
P-9	GND	Power ground (26 V return)
P-10	GND	Power ground (26 V return)
P-11	RS422_TX+	Laser Rangefinder/Designator Transmit (+)
P-12	RS422_TX–	Laser Rangefinder/Designator Transmit (–)
P-13	RS422_RX–	Laser Rangefinder/Designator Receive (–)
P-14	RS422_RX+	Laser Rangefinder/Designator Receive (+)
P-15	GND	Signal ground

Technical drawings

LDR40K3 — Weight Requirement

Detailed LDR20K1 Specifications

The technical material below is retained for this model only. Do not transfer a range, pulse, interface, mechanical or safety value from another 1064 nm product.

Specifications

The tables below retain the supplied model record except for entries explicitly withheld after a comparison with the current model PDF. A value, option or condition from another model is not interchangeable. General explanations are separated from model-specific entries.

Source-review note

The old range and code-accuracy summary contains unsupported qualifiers. The current document also has a TTL/RS422 interface-title inconsistency; those terms must not be treated as interchangeable. The old outline image with malformed annotation is withdrawn.

Current LDR20K1 document — source checked 13 September 2026. On a small screen, swipe wide tables horizontally to read every column.

LDR20K1 — Technical Specifications

Operating modes	Ranging, designation
Pump source	Diode array
Operating wavelength	1.064 μm (1064 nm)
Pulse energy	≥ 20 mJ
Pulse energy stability	Within a single designation cycle, single-pulse energy deviation ≤ ±10% (after 2 s of emission)
Beam divergence	≤ 0.6 mrad
Pulse width	10 ns ± 5 ns
Laser optical-axis stability	≤ 0.05 mrad
Ranging performance
Ranging frequency	1 Hz / 5 Hz / single-shot
Continuous ranging	1 Hz: ≥ 5 min; 5 Hz: ≥ 1 min
Measurement range	Withheld pending a corrected, controlled model specification. See the source-review note above.
Ranging accuracy	±1 m
Detection rate	≥ 98%
Dimensions	≤ 92 mm × 67 mm × 53 mm
Weight	≤ 290 g
Designation performance
Laser code accuracy	Withheld pending a corrected, controlled model specification. See the source-review note above.
Designation frequency	20 Hz fundamental (supports user-defined coding)
Environmental Adaptability
Operating temp	–40°C to +55°C
Storage temp	–45°C to +70°C

LDR20K1 — PIN INTERFACE

Pin No.	Signal Name	Description
1	Vin	Power supply +(24V)
2	Vin	Power supply +(24V)
3	GND	Power return (–)
4	GND	Power return (–)
5	RX1+	Host Computer -> Laser Range & Illumination Unit (422-RX+)
6	RX1-	Host Computer -> Laser Range & Illumination Unit (422-RX-)
7	TX1-	Laser Range & Illumination Unit -> Host Computer (422-TX-)
8	TX1+	Laser Range & Illumination Unit -> Host Computer (422-TX+)
External Trigger
1	TBI	External Trigger + (Rising edge trigger)
2	TBG	External Trigger -

Technical drawings

LDR20K1 — PIN INTERFACE

Detailed LRF1500H Specifications

Every value below is bound to the model source named on this page. Qualifiers and test conditions are retained; missing values are not inferred.

Functional Description

The source states that 1 kHz or 50 Hz is selected automatically to match reflected-signal intensity.

The product is designed as a module for customer secondary development and integration.

Electrical Interface Definition

Signal names and directions are transcribed from the model source.

Mechanical Dimension Drawing and Electrical Interface Diagram

These figures are extracted from the named model source without generative modification.

Electrical interface definitionFive-pin power, ground and UART TX/RX definition extracted from page 3.Mechanical dimension drawingTwo-dimensional 33 × 34 × 18 mm source drawing extracted from page 3.

Detailed LRF300H Specifications

Every value below is bound to the model source named on this page. Qualifiers and test conditions are retained; missing values are not inferred.

Functional Description

The source states that 1 kHz or 50 Hz is selected automatically to match reflected-signal intensity.

The product is designed as a module for customer secondary development and integration.

Electrical Interface Definition

Signal names and directions are transcribed from the model source.

Mechanical Dimension Drawing and Electrical Interface Diagram

These figures are extracted from the named model source without generative modification.

Electrical interface definitionFive-pin power, ground and UART TX/RX definition extracted from page 3.Mechanical dimension drawingTwo-dimensional 33 × 34 × 18 mm source drawing extracted from page 4.

Detailed LRF600H Specifications

Every value below is bound to the model source named on this page. Qualifiers and test conditions are retained; missing values are not inferred.

Functional Description

The source states that 1 kHz or 50 Hz is selected automatically to match reflected-signal intensity.

The product is designed as a module for customer secondary development and integration.

Electrical Interface Definition

Signal names and directions are transcribed from the model source.

Mechanical Dimension Drawing and Electrical Interface Diagram

These figures are extracted from the named model source without generative modification.

Electrical interface definitionFive-pin power, ground and UART TX/RX definition extracted from page 3.Mechanical dimension drawingTwo-dimensional 33 × 34 × 18 mm source drawing extracted from page 3.

Detailed LRF100H Specifications

Every value below is bound to the model source named on this page. Qualifiers and test conditions are retained; missing values are not inferred.

Functional Description

The source states resistance to strong electromagnetic interference for positioning or collision-avoidance monitoring of land transport vehicles and overhead bridge cranes.

Electrical Interface Definition

Signal names and directions are transcribed from the model source.

Mechanical Dimension Drawing and Electrical Interface Diagram

These figures are extracted from the named model source without generative modification.

Electrical interface definitionFive-pin 9-36 V power, ground and UART TX/RX definition extracted from page 3; no unstated IIC pin mapping is added.Mechanical dimension drawingTwo-dimensional 33 × 34 × 18 mm source drawing extracted from page 3.

Detailed LRF50H Specifications

Every value below is bound to the model source named on this page. Qualifiers and test conditions are retained; missing values are not inferred.

Functional Description

The coaxial 650 nm aiming light can be switched on or off to support alignment and installation.

The source states that the aiming light automatically turns off below -20°C and that the specified operating range requires no condensation.

Electrical Interface Definition

Signal names and directions are transcribed from the model source.

Mechanical Dimension Drawing and Electrical Interface Diagram

These figures are extracted from the named model source without generative modification.

Electrical interface definitionFive-pin 9-36 V power, dual-ground and UART TX/RX definition extracted from page 3.Mechanical dimension drawingTwo-dimensional 38 × 20 × 30 mm source drawing extracted from page 3.

Detailed LRF50VB Specifications

Every value below is bound to the model source named on this page. Qualifiers and test conditions are retained; missing values are not inferred.

Functional Description

The formal specification states a 100 Hz measurement frequency.

The formal specification lists UART/IIC as the communication interface.

The source describes flexible installation and expansion for drones, sweeping robots and industrial robots.

Electrical Interface Definition

Signal names and directions are transcribed from the model source.

Mechanical Dimension Drawing and Electrical Interface Diagram

These figures are extracted from the named model source without generative modification.

Electrical interface definitionFour-pin source interface showing the UART RX/TX and IIC SDA/SCL assignments on page 3.Mechanical dimension drawingTwo-dimensional 18.7 × 11.8 × 13.3 mm source drawing extracted from page 3.Measurement spot referenceSource page 4 associates the 1.9° emission field with spot diameters of 3, 6, 15, 30 and 60 cm at 1, 2, 5, 10 and 20 m respectively.

Meet the LR2000E4

The LR2000E4 is a compact ranging module in the E4 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–2000 m. For distances above 400 m, the accuracy table uses a distance-dependent term of 0.4% of D. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E4 drawing for packaging and mounting; an E2 drawing is not an interchangeable mechanical reference.

LR2000E4 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 2–10 Hz (adaptive). Use the current protocol table for command timing and output format.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR2000E4 user manual.

LR2000E4 Mechanical DrawingManual page 4. Open the PDF to inspect the original dimensions and tolerances.

Detailed LRF10VB Specifications

Every value below is bound to the model source named on this page. Qualifiers and test conditions are retained; missing values are not inferred.

Functional Description

The source states that the sensor uses the direct time-of-flight principle and transmits distance information through UART.

The source front page reports a 1 mm resolution; this is not an accuracy value.

The formal specification states support for a low-power mode.

Electrical Interface Definition

Signal names and directions are transcribed from the model source.

Mechanical Dimension Drawing and Electrical Interface Diagram

These figures are extracted from the named model source without generative modification.

Electrical interface definitionFour-pin TX, RX, GND and 5 V interface extracted without generative editing from LRF10VB Specification V3.0 page 3.Mechanical dimension drawingTwo-dimensional source drawing for the 12 × 7.5 × 9.1 mm module, extracted without generative editing from page 3.

Meet the LRF3000A1

The LRF3000A1 extends this selection to a 3000 m range class while keeping a TTL-level UART host interface. The maximum-range condition is explicit: a building target with 70% reflectivity, clear weather, and visibility of at least 4 km.

The minimum-range entry is 1 m on a 90%-reflectivity whiteboard. These minimum and maximum figures use different targets; they should not be combined into an unconditional all-target range guarantee.

Normal mode provides a 3–10 Hz adaptive update rate, while long-range mode is specified at 1–10 Hz. The electrical specification allows 3.3–5 V DC with supply ripple below 0.1 V.

LRF3000A1 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• Use the model-specific mechanical drawing for the mounting geometry and tolerances. Overall installation clearance is evaluated separately from individual housing dimensions.
• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Select normal or long-range measurement mode through the model’s communication protocol. The mode determines the documented adaptive output-rate range.

In low-power mode the controller is off and does not respond to ordinary commands. Use the model-specific enable input and wake-up sequence before requesting or processing a ranging result.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LRF3000A1 user manual.

LRF3000A1 Mechanical DrawingManual page 5. Open the PDF to inspect the original dimensions and tolerances.

Meet the LR2000E2

The LR2000E2 is a compact ranging module in the E2 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–2000 m. For distances above 400 m, the accuracy table uses a distance-dependent term of 0.4% of D. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E2 drawing for packaging and mounting.

LR2000E2 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 2–10 Hz (adaptive). Use the current protocol table for command timing and output format.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR2000E2 user manual.

LR2000E2 Mechanical DrawingManual page 4. Open the PDF to inspect the original dimensions and tolerances.

Meet the LR1500E2

The LR1500E2 is a compact ranging module in the E2 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–1500 m. The accuracy table uses a 500 m breakpoint, with a separate distance-dependent formula for longer measurements. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E2 drawing for packaging and mounting.

LR1500E2 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 2–10 Hz (adaptive). Higher-rate custom versions mentioned in the manual are separate configurations, not the default performance of a standard unit.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR1500E2 user manual.

LR1500E2 Mechanical DrawingManual page 4. Open the PDF to inspect the original dimensions and tolerances.

Meet the LR1500E4

The LR1500E4 is a compact ranging module in the E4 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–1500 m. Accuracy is specified in two distance intervals, with a distance-dependent term above 400 m. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E4 drawing for packaging and mounting; an E2 drawing is not an interchangeable mechanical reference.

LR1500E4 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 2–10 Hz (adaptive). Higher-rate custom versions mentioned in the manual are separate configurations, not the default performance of a standard unit.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR1500E4 user manual.

LR1500E4 Mechanical DrawingManual page 4. Open the PDF to inspect the original dimensions and tolerances.

Compact Ranging with Laser Indication

SPD1200N3 combines a 905 nm ranging laser and single-photon receiver with a laser-indication function. ERDI confirms that its ranging laser and receiver are shared with SPD1200ZG; the model-specific ranging limits, mechanical design and indication functions must still be evaluated separately.

SPD1200ZG provides inertial orientation information. SPD1200N3 provides laser indication instead; this is not a claim of a six-axis IMU, compass heading or 3D point-to-point measurement for N3.

The N3 specification states a 3–1000 m range on a building target under visibility of at least 10 km and humidity no greater than 60%. The nominal rectangular body is 14 × 18 × 22.3 mm and weighs no more than 6 g.

Detailed SPD1200N3 Specifications

Read the values together with their source conditions. Literature and related-model data do not replace these ratings.

Functional Description

Single measurement initiates one target-distance measurement and returns the result over the serial interface; the source describes repeated acquisition for low-reflectivity targets until a stable reading is obtained.

Continuous measurement repeatedly reports target distance at a distance-dependent 2.5–15 Hz update rate.

The serial baud rate can be configured to match host requirements. Use firmware-matched packet definitions and test command, response, checksum and failure handling on the ordered configuration.

Electrical Interface Definition

Check the numbered connector view before wiring. Supply voltage and UART input tolerance are different electrical limits.

Mechanical Dimension Drawing and Electrical Interface Diagram

Mechanical dimensions and six-pin electrical interfaceDrawing extracted without generative editing from the N3 source. The nominal body is 14 × 18 × 22.3 mm; use the drawing tolerances, datum and pin orientation. “Launch” identifies the transmit aperture and “Receive” the receive aperture.

Distance, Attitude, and Relative 3D Measurement

The SPD1200ZG combines compact 905 nm pulsed laser ranging with integrated inertial angle sensing for OEM systems that need distance, attitude, and relative three-dimensional point-to-point measurement in one lightweight module.

It supports single and continuous ranging, configurable angle reporting, and UART-TTL communication for host integration.

Nominal body dimensions are 7.2 × 14.7 × 22.3 mm and weight is no more than 5 g; the complete installation envelope is governed by the current mechanical drawing.

SPD1200ZG Specifications

Read each performance value with its stated target, environmental, operating, and installation conditions.

Optical and ranging

Electrical and environmental

Mechanical

Inertial measurement

3D point-to-point — radial error

3D point-to-point — static maximum absolute error

3D point-to-point — dynamic maximum absolute error

Pulsed Time of Flight and SPAD Reception

Six-Axis Inertial Measurement Explained

A conventional six-axis IMU comprises three orthogonal gyroscope angular-rate channels and three orthogonal accelerometer specific-force channels. Six-axis describes six sensing channels, not six independent rotational axes. [6]

Angle reporting is configurable and does not imply that the standard customer interface exposes all six raw sensor channels. Available outputs are defined by the configuration-matched interface protocol.

For a fixed single-axis rotation, the conceptual relationship is θ(t) = θâ‚€ + ∫ω(t)dt. Angular-rate bias and noise create accumulated angle drift. Three-axis attitude estimation requires an appropriate coordinate convention. [5]

Integration error accumulates during motion. This is relative heading, not an absolute north-referenced compass specification.

Coordinate Convention

Use the current manual's X/Y/Z convention when interpreting angle-enabled output.

Coordinate AxesThe Y axis points toward the lenses. Use the coordinate convention in the current user manual.

SPD1200N2 OEM Ranging and Integration

SPD1200N2 is a compact 905 nm laser ranging module with a 0.2–1200 m source-table ranging distance. The source documents UART-TTL communication and a model-specific square housing. The specifications, drawings and electrical definitions below remain bound to this model. The technical literature section explains general principles without asserting an undocumented receiver architecture.

Detailed SPD1200N2 Specifications

Read the values together with their source conditions. Literature and related-model data do not replace these ratings.

Functional Description

The source lists baud-rate modification as a serial-interface function.

Single ranging measures the target once. For a low-reflectivity target, the source says the module repeats measurements until stable distance data is obtained and reports it through the serial interface.

Repeated-ranging mode performs continuous distance measurement. The functional section states a typical configurable 2 Hz refresh rate and a maximum of 15 Hz; the formal frequency row separately retains both 2–15 Hz and 4–15 Hz alternatives.

Electrical Interface Definition

Check the numbered connector view before wiring. Supply voltage and UART input tolerance are different electrical limits.

Mechanical Dimension Drawing and Electrical Interface Diagram

Source product viewModel-specific product figure extracted directly from the controlled SPD1200N2 PDF without generative editing.Mechanical dimension and pin-callout drawingModel-specific source drawing with visible dimensions and physical pin callouts 1–6 retained.Optical-window installation referenceSource optical-window arrangements with source variables and dimensional relationships retained.

SPD1200N4 OEM Ranging and Integration

SPD1200N4 is a compact 905 nm laser ranging module with a 0.2–1200 m source-table ranging distance. The source documents UART-TTL communication for model-specific integration review. The specifications, drawings and electrical definitions below remain bound to this model. The technical literature section explains general principles without asserting an undocumented receiver architecture.

Detailed SPD1200N4 Specifications

Read the values together with their source conditions. Literature and related-model data do not replace these ratings.

Functional Description

The source lists baud-rate modification as a serial-interface function.

Single ranging measures the target once. For a low-reflectivity target, the source says the module repeats measurements until stable distance data is obtained and reports it through the serial interface.

Repeated-ranging mode performs continuous distance measurement. The functional section states a typical configurable 2 Hz refresh rate and a maximum of 15 Hz; the formal frequency row separately retains both 2–15 Hz and 4–15 Hz alternatives.

Electrical Interface Definition

Check the numbered connector view before wiring. Supply voltage and UART input tolerance are different electrical limits.

Mechanical Dimension Drawing and Electrical Interface Diagram

Source product viewModel-specific product figure extracted directly from the controlled SPD1200N4 PDF without generative editing.Mechanical dimension and pin-callout drawingModel-specific source drawing with visible dimensions and physical pin callouts 1–6 retained.Optical-window installation referenceSource optical-window arrangements with source variables and dimensional relationships retained.

Meet the LR1200E4

The LR1200E4 is a compact ranging module in the E4 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–1200 m. Accuracy is specified in two distance intervals, with a distance-dependent term above 400 m. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E4 drawing for packaging and mounting; an E2 drawing is not an interchangeable mechanical reference.

LR1200E4 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 2–10 Hz (adaptive). Higher-rate custom versions mentioned in the manual are separate configurations, not the default performance of a standard unit.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR1200E4 user manual.

Meet the LRF1200A1

The LRF1200A1 is a cylindrical ranging module for compact instruments that need a serial distance output. Its specification lists a building-target measurement range of 5–1200 m and an update rate of 1–3 Hz.

The 0.1 m display increment is distinct from ranging accuracy. Accuracy is ±1 m from 5 to 100 m and follows a distance-dependent formula above 100 m. This distinction helps define a realistic display and acceptance test.

Electrical integration differs from the E series: the specified supply is 3.3 ± 0.1 V DC, not a general 3.3–5 V input range. Use the LRF1200A1 pin definition, low-power behavior, and communication protocol.

LRF1200A1 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

The host uses the serial communication protocol to operate the ranging module. The low-power mode turns the controller off, so it does not respond to normal commands while asleep.

The manual describes an active-low enable input for normal operation and a high level for low-power mode. Use the LRF1200A1 interface and timing definitions rather than an E-series wiring assumption.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LRF1200A1 user manual.

SPD1200N0 OEM Ranging and Integration

SPD1200N0 is a compact 905 nm laser ranging module with a 0.2–1200 m source-table ranging distance. The source documents UART-TTL communication and a circular housing specific to this model. The specifications, drawings and electrical definitions below remain bound to this model. The technical literature section explains general principles without asserting an undocumented receiver architecture.

Detailed SPD1200N0 Specifications

Read the values together with their source conditions. Literature and related-model data do not replace these ratings.

Functional Description

The source lists baud-rate modification as a serial-interface function.

Single ranging measures the target once. For a low-reflectivity target, the source says the module repeats measurements until stable distance data is obtained and reports it through the serial interface.

Repeated-ranging mode performs continuous distance measurement. The functional section states a typical configurable 2 Hz refresh rate and a maximum of 15 Hz; the formal frequency row separately retains both 2–15 Hz and 4–15 Hz alternatives.

Electrical Interface Definition

Check the numbered connector view before wiring. Supply voltage and UART input tolerance are different electrical limits.

Mechanical Dimension Drawing and Electrical Interface Diagram

Source product viewModel-specific product figure extracted directly from the controlled SPD1200N0 PDF without generative editing.Mechanical dimension and pin-callout drawingModel-specific source drawing with visible dimensions and physical pin callouts 1–6 retained.Optical-window installation referenceSource optical-window arrangements with source variables and dimensional relationships retained.

Meet the LR1000E2

The LR1000E2 is a compact ranging module in the E2 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–1000 m. Accuracy is specified in two distance intervals, with a distance-dependent term above 400 m. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E2 drawing for packaging and mounting.

LR1000E2 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 3–10 Hz (adaptive). Use the current protocol table for command timing and output format.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR1000E2 user manual.

Meet the LR1000E4

The LR1000E4 is a compact ranging module in the E4 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–1000 m. Accuracy is specified in two distance intervals, with a distance-dependent term above 400 m. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E4 drawing for packaging and mounting; an E2 drawing is not an interchangeable mechanical reference.

LR1000E4 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 3–10 Hz (adaptive). Higher-rate custom versions mentioned in the manual are separate configurations, not the default performance of a standard unit.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR1000E4 user manual.

Meet the LR1200E2

The LR1200E2 is a compact ranging module in the E2 mechanical format. It provides digital distance measurements for equipment that needs a ranging subsystem rather than a standalone handheld meter.

Its standard measurement range is 4–1200 m. The accuracy table uses a 500 m breakpoint, with a separate distance-dependent formula for longer measurements. Use the model-specific accuracy formula when setting your system requirements.

The UART-TTL interface supports host-controlled measurements. The manual includes test-software guidance, a six-pin interface definition, and a hexadecimal communication protocol. Use the E2 drawing for packaging and mounting.

LR1200E2 Specifications

Read performance values with their target and test conditions. The linked user manual provides the complete mechanical, electrical, and communication details.

• For civilian equipment only. The model manual prohibits military applications.

Operation and Data Output

Single-shot mode requests one reported distance. For a weak return, the manual describes repeated internal measurements before reporting stable distance data. Continuous mode produces repeated results at the documented adaptive update rate.

The standard measurement-rate specification is 2–10 Hz (adaptive). Higher-rate custom versions mentioned in the manual are separate configurations, not the default performance of a standard unit.

Electrical Interface

Mechanical Dimensions

Use the drawing and its tolerances for installation. This drawing is reproduced directly from the current LR1200E2 user manual.

Technical specifications

Values are transcribed from the HW256 controlled user manual. Conditions are retained. This page is a product reference, not an independent test report or certification.

Optical

Power

Thermal imaging

Adjustment, mounting, physical and environmental

HW256 at a glance

The HW256 is a compact 1× thermal fusion sight that combines a red-dot aiming channel with an uncooled thermal imaging channel in one housing. The red dot gives rapid target acquisition and a precise aiming point; the thermal channel renders target outlines and scene detail in low light, darkness, smoke and dust. The sight therefore remains usable by day and by night without changing hardware.

A 1× optical system is used with both eyes open, so the HW256 can be brought onto a target in the same way as a conventional red-dot sight. Thermal imagery is presented on an OLED display and can be viewed together with the red-dot reticle for fusion observation. The detector resolves 256 × 192 pixels on a 12 µm pitch behind a 19 mm lens, giving a 9° × 6.7° field of view.

The housing is machined from aircraft-grade aluminium with a black hard-anodised finish. A standard Picatinny interface with a quick-release lever allows tool-free fitting and removal, and the 38 mm optical-axis height matches common rail and mount combinations. The supplied document describes intended use for close- to medium-range work on submachine guns, assault rifles and similar platforms, including urban operations and indoor CQB, subject to local law.

Key features

• Thermal and red dot in one sight for day and night use.
• Three reticle styles: dot, circle, and dot with circle.
• Three thermal image modes: black hot, white hot and outline.
• 256 × 192 uncooled vanadium-oxide detector, 12 µm pixel pitch, 19 mm lens, 9° × 6.7° field of view.
• OLED display, 1024 × 768 pixels.
• 1× / 3× / 5× digital zoom; digital zoom reduces the field of view.
• 15 daylight + 5 night-vision red-dot levels and 10 thermal brightness levels.
• Red-dot-only runtime ≥ 10,000 h; fusion-mode runtime ≥ 6 h.
• Full CNC aluminium housing with black hard-anodised finish for rigidity and stable zero retention.
• 30 × 23 mm viewing window and a quick-release Picatinny mount with a clamp-adjustment knob.
• IP67 sealed housing, stated for −20 °C to +65 °C operation.

How thermal fusion works

Every object above absolute zero emits infrared radiation, and the amount and spectrum depend on its temperature and emissivity. An uncooled thermal detector converts the incoming long-wave infrared radiance into an electrical signal and then into a visible image. Warmer objects can be displayed brighter (white hot) or darker (black hot), or rendered as an outline that emphasises temperature transitions.

The HW256 adds a red-dot aiming channel to that thermal image. The red dot provides a precise, high-contrast aiming point for rapid acquisition, while the thermal channel reveals target outlines that may be difficult to see with a conventional optic in low light, darkness, smoke or dust. Presenting both channels in one 1× sight avoids switching hardware between day and night configurations.

Thermal imagery is not a photograph and is not a calibrated temperature map. Image contrast depends on the temperature difference between the target and its background, atmospheric transmission, distance, focus and the selected palette. The HW256 is an imaging and aiming sight, not a radiometric thermometer.

Performance conditions and limits

• Thermal contrast depends on the target-to-background temperature difference and emissivity. A scene with little thermal contrast may show little detail even when the detector is working correctly.
• Atmospheric transmission is reduced by fog, heavy rain, dust, smoke and long distance. Thermal imaging can help in smoke or dust, but it does not guarantee seeing through every obscurant.
• Ordinary glass blocks much of the long-wave infrared band used by thermal imagers. A thermal sight generally cannot image through a closed window or glass barrier; confirm the optical path.
• Runtime depends on mode, brightness, zoom, calibration frequency, battery type and temperature. The quoted red-dot-only and fusion-mode figures are separate operating conditions.
• Digital zoom enlarges the central part of the image; it does not add optical resolution or target detail.
• IP67 is a manufacturer-stated rating. IEC 60529 defines the IP code; citing the standard does not certify this product. IP67 is not a diving or high-pressure-washing rating.
• Zero retention after removal, impact or mount changes must be confirmed on the host; the supplied manual describes the inspection and adjustment process.

Intended use and application scenarios

The supplied document describes the HW256 for close- to medium-range work on submachine guns, assault rifles and similar platforms, including urban operations and indoor CQB. It is an aiming aid: it does not replace safe firearm handling, marksmanship training or compliance with local law.

• Day/night patrol and security use where both a rapid red-dot aim point and thermal target detection are useful.
• Urban and indoor close-quarters scenarios where target outlines may be obscured by low light, shadow, smoke or dust.
• Hunting where lawful, particularly in low-light conditions where thermal contrast reveals animals against vegetation or ground.
• Sport shooting and professional training on 1913-rail rifles and carbines.
• Observation and detection of heat-emitting targets before positive identification with other sensors or lighting.

Application examples describe configuration possibilities, not a guarantee of detection, identification, hit probability or legality in a particular jurisdiction. Confirm local law and range rules before use.

Mounting, power and configuration

The HW256 fits a MIL-STD-1913 Picatinny rail with its quick-release mount. Confirm that the rail and mount are mechanically sound, that the mount is fully seated and locked, and that the sight cannot move by hand before use. The 38 mm optical-axis height should be checked against the host’s stock, cheek weld and any magnifier or clip-on.

Power is supplied by one CR123A cell (3 V or 3.7 V). The Type-C 5 V input can power the sight but does not charge the cell according to the manual. The red dot and thermal channel have separate power and brightness logic; the supplied manual gives the complete button, reticle, zoom, calibration and inspection procedure. This page intentionally does not reproduce operating instructions.

Thermal performance is configuration-dependent. Confirm the image focus, palette, brightness and reticle for the intended environment, and verify zero after mounting or changing the host configuration.

Care, storage and safety

• Wipe outer surfaces with a cloth moistened with water, mild soap solution or alcohol. Blow loose particles off the optics, then clean the glass with a lens tissue and an optical solvent.
• Clean the battery compartment with a suitable solvent and let it dry fully. Check the mount, O-rings and covers periodically.
• If the sight is not used for a long period, remove the cell, store it in a dry, dust-free place below 80 % relative humidity, away from acids, alkalis and corrosive vapours, and check the sight every three months.
• Do not open the housing, modify the sight or attempt repairs. Refer visible damage or unexplained faults to qualified service personnel.
• Before installing, adjusting or servicing the sight, make sure the firearm is unloaded, the chamber is empty and the muzzle is pointed in a safe direction. Wear eye and hearing protection when shooting.
• Do not point the sight at the Sun, lasers, welding equipment or other high-intensity heat sources. Do not use it as solar-viewing equipment.
• Do not dispose of lithium cells with household waste; follow local recycling and disposal rules.


Technical specifications

Values are transcribed from the QX500B1 controlled user manual, revision v5 dated 18 October 2026. Values are controlled acceptance limits under the corresponding test conditions. This page is a product reference, not an independent test report or certification.

Optical
