Stabilizing the U30TIR-50 is a highly optimized 2-axis camera gimbal with pinpoint-precise motor rotation with a control accuracy of ±0.01° powered by a dedicated processor. U30TIR-50 is a powerful dual-sensor gimbal camera with 30 times optical zoom camera and 50mm lens thermal imager. It’s powered by SONY 1/2.8”“Exmor R”CMOS module, 2.13 mega effective pixels, FHD 1080p video, fast auto-focus speed. The high-precision camera module and advanced pinpoint anti-vibration system create high quality image at anytime. With strong 50mm lens thermal imager, U30TIR-50 is engineered for day & night surveillance, search, inspection and firefighting.
Specification
Hardware Parameter | |
Working voltage | 12V ~ 16V |
Input voltage | 4S |
Output voltage | 5V (connect with PWM) |
Dynamic current | 500mA @ 12V |
Idle current | 400mA @ 12V |
Power consumption | ≤ 6W |
Working environment temp. | -20? ~ +60? |
Output | micro HDMI(HD output 1080P 60fps) / IP / SDI |
Local-storage | SD card (Up to 128G, class 10, FAT32 or ex FAT format) |
Control method | PWM / TTL / S.BUS |
Gimbal Spec | |
Pitch/Tilt | ±90° |
Roll | None |
Yaw/Pan | ±170°(HDMI output) / ±360°*N (IP/SDI output) |
Vibration angle | Pitch: ±0.01°, Yaw?±0.01° |
One-key to center | √ |
Camera Spec | |
Imager Sensor | SONY 1/2.8" "Exmor R" CMOS |
Picture quality | Full HD 1080 (1920*1080) |
Effective pixel | 2.13MP |
Lens optical zoom | 30x, F=4.3~129mm |
Digital zoom | 12x (360x with optical zoom) |
Min object distance | 10mm(wide end) to 1200mm(tele end). Default 300mm |
Horizontal viewing angle | 1080p mode: 63.7°(wide end) ~ 2.3°(tele end) |
720p mode: 63.7°(wide end) ~ 2.3°(tele end) | |
SD: 47.8°(wide end) ~ 1.7°(tele end) | |
Sync system | Internal |
S/N ratio | more than 50dB |
Min illumination | Color 0.01lux@F1.6 |
Exposure control | Auto, Manual, Priority mode(shutter priority & iris priority), Bright, EV compensation, Slow AE |
Gain | Auto/Manual 0dB to 50.0dB(0 to 28 steps + 2 setep/ total 15 steps) Max.Gain Limit 10.7 dB to 50.0dB (6 to 28 steps + 2 step/ total 12 steps) |
White balance | Auto, ATW, Indoor, Outdoor, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto/Outdoor Auto), One-push, Manual |
Shutter speed | 1/1s to 1/10,000s, 22 steps |
Backlight compensation | Yes |
Aperture control | 16 steps |
Defog | Yes |
OSD | Yes |
Fotoformate | JPEG |
Videoformate | MP4 |
Camera Object Tracking | |
Update rate of deviation pixel | 50Hz |
Output delay of deviation pixel | <15ms |
Minimum object contrast | 5% |
SNR | 4 |
Minimum object size | 16*16 pixel |
Maximum object size | 160*160 pixel |
Tracking speed | ±32 pixel/frame |
Object memory time | 100 frames (4s) |
The mean square root values of pulse noise in the object position | < 0.5 pixel |
Thermal Imager Spec | |
Lens size | 50mm |
Horizontal FOV(°) | 12.4 |
Vertical FOV(°) | 9.3 |
Diagonal FOV(°) | 15.5 |
Detective Distance (Man: 1.8x0.5m) | 1471 meters |
Recognize Distance (Man: 1.8x0.5m) | 368 meters |
Verified Distance (Man: 1.8x0.5m) | 184 meters |
Detective Distance (Car: 4.2x1.8m) | 4510 meters |
Recognize Distance (Car: 4.2x1.8m) | 1127 meters |
Verified Distance (Car: 4.2x1.8m) | 564 meters |
Working mode | Uncooled long wave (8μm~14μm) thermal imager |
Detector pixel | 640*480 |
Pixel size | 17μm |
Focusing method | Athermal prime lens |
Emissivity correction | 0.01~1 |
NETD | ≤50mK (@25?) |
MRTD | ≤650mK (@characteristic frequency) |
Image enhancement | Auto adjust image brightness and contrast ratio |
Color palette | White, iron red, pseudo color |
Auto Non-uniform correction | Yes (no shutter) |
Digital zoom | 1x, 3x (max 6x) |
Sync correct time | Yes |
Thermometry type | Temperature bar (psudo color display) max temp, min temp, FOV center temp (Optional) |
Temperature warning | 0?~100? |
Thermal Object Tracking | |
Update rate of deviation pixel | 25Hz |
Output delay of deviation pixel | <3ms |
Minimum object size | 16*16 pixel |
Maximum object size | 128*128 pixel |
Tracking speed | ±32 pixel/frame |
Object memory time | 100 frames (4s) |
Packing Information | |
N.W. | 2500g |
Product meas. | 227*190*170mm |
