| Hardware Parameter |
| Working voltage |
12V |
| Input voltage |
4S ~ 6S |
| Output voltage |
5V (connect with PWM) |
| Dynamic current |
550mA @ 12V |
| Idle current |
450mA @ 12V |
| Power consumoption |
≤ 6.6W |
| Working environment temp. |
-20?~+50? |
| Output |
micro HDMI(1080P 60fps) / IP |
| Local-storage |
TF card (Up to 128G, class 10, FAT32 or ex FAT format) |
| Control method |
PWM / TTL / S.BUS / TCP |
| Gimbal Spec |
| Pitch/Tilt |
+90° |
| Roll |
±85° |
| Yall/Pan |
±170°/±360°*N |
| Vibration angle |
Pitch/Roll: ±0.01°, Yaw?±0.01° |
| One-key to center |
√ |
| Camera spec |
| Imager Sensor |
SONY 1/3" CMOS |
| Picture quality |
Full HD 1080 (1920*1080) |
| Effective pixel |
4.08MP |
| Lens optical zoom |
10x, F=3.2~33.6mm |
| Digital zoom |
None |
| Min object distance |
10mm(wide end) to 800mm(tele end) |
| Horizontal viewing angle |
59.2°(wide end) ~ 6.7°(tele end) |
| Sync system |
Internal |
| S/N ratio |
more than 52dB |
| Min illumination |
0.5 lx(1/30s, F1.8, 50%) |
| Gain |
Auto / Manual |
| White balance |
ATW1(Narrow), ATW2(Wide), single touch, manual(B,R) |
| Shutter speed |
1/1s to 1/10,000s, 22 steps |
| Backlight compensation |
Yes |
| Aperture control |
16 steps |
| OSD |
Yes |
| Camera Object Tracking |
| Update rate of deviation pixel |
50Hz |
| Output delay of deviation pixel |
< 10ms |
| Minimum object contrast |
5% |
| SNR |
4 |
| Minimum object size |
32*32 pixel |
| Maximum object size |
128*128 pixel |
| Tracking speed |
±48 ~ ±192 pixel/frame |
| Object memory time |
100 frames (4s) |
| The mean square root values of pulse noise in the object position |
< 0.5 pixel |
| Thermal Imager Spec |
| Lens size |
35mm |
| Horizontal FOV |
17.7° |
| Vertical FOV |
13.3° |
| Diagonal FOV |
22° |
| Detective Distance (Man: 1.8x0.5m) |
1029 meters |
| Recognize Distance (Man: 1.8x0.5m) |
257 meters |
| Verified Distance (Man: 1.8x0.5m) |
129 meters |
| Detective Distance (Car: 4.2x1.8m) |
3157 meters |
| Recognize Distance (Car: 4.2x1.8m) |
789 meters |
| Verified Distance (Car: 4.2x1.8m) |
395 meters |
| Working mode |
Uncooled long wave (8μm~14μm) thermal imager |
| Detector pixel |
640*480 |
| Pixel size |
17μm |
| Focusing method |
Athermal prime lens |
| Emissivity correction |
0.01~1 |
| NETD |
≤50mK (@25?) |
| MRTD |
≤650mK (@characteristic frequency) |
| Image enhancement |
Auto adjust image brightness and contrast ratio |
| Color palette |
White, iron red, pseudo color |
| Auto Non-uniform correction |
Yes (no shutter) |
| Digital zoom |
1x, 3x |
| Sync correct time |
Yes |
| Thermometry type |
Temperature bar (psudo color display) max temp, min temp, FOV center temp (Optional) |
| Temperature warning |
0?~100? |
| Thermal Imager Object Tracking |
| Update rate of deviation pixel |
30Hz |
| Output delay of deviation pixel |
?3ms |
| Minimum object size |
32*32 pixel |
| Maximum object size |
128*128 pixel |
| Tracking speed |
±48 ~ ±192 pixel/frame |
| Object memory time |
100 frames (4s) |
| Packing Information |
| N.W. |
676g |
| Product meas. |
113*113*157mm |
| Accessories |
1pc gimbal camera device, 16pcs screws, 4pcs copper cylinders, 12pcs damping balls, 4pcs damping boards, 1pc USB to TTL cable / Hight quality plastic box with foam cushion |
| G.W. |
2860g |
| G.W.Package meas. |
300*250*200mm |
