2. Waterproof performance: IP67.

3. Precision metal steering gear.

4. Widely Use Digital Servo:The steering servo (Control Angle 180°) Compatible with 1/5, Scale Clawer Truck, Traxxas,

Description:

600KG Large torque Digital Waterproof servo,adopt Brushless motor,Compared with ordinary servo, the speed is much faster and the reaction is also fast,24V High Operation Voltage Range,

It's a good accessory for your RC RC Car Truck Crawler Boat Robot and DIY model toy!

Specifications:

Brand: GXservo

Model: GX93600BLS

Puise Width: 500μs-2500μs =180°/270°/360°

Operating Speed: (20V)0.37sec60°

Operating Speed: (24V)0.3sec60°

Stall Torque(20V): 450kg.cm

Stall Torque(24V): 600kg.cm

Operating Voltage: 20V-30V

Gear Type: Steel

Motor: Brushless motor

Ball Bearing: 2BB

Working Frequence: 1520μs/330hz

Dimensions: 132*55.3*100mm

Shell Materal: CNC aviation aluminium alloy

spline tooth? 25T

Control System: Customizable(PWM,RS485 ,TTL,CAN)

Weight: 1.066kg

Specifications

Is Electric

No battery

Quantity

1 pcs

Model Number

GX93600BLS

Remote Control Peripherals/Devices

Servos

RC Parts & Accs

Servos

Material

Metal

Brand Name

GXservo

Origin

Mainland China

Recommend Age

14+y

Use

Vehicles & Remote Control Toys

2. Waterproof performance: IP67.

3. Precision metal steering gear.

4. Widely Use Digital Servo:The steering servo (Control Angle 180°) Compatible with 1/5, Scale Clawer Truck, Traxxas, scx10, RC Car / Robot / Boat and other remote control models.

Description:

80KG Large torque Digital Waterproof servo,adopt Coreless motor,Compared with ordinary servo, the speed is much faster and the reaction is also fast,6.0V ~8.4V High Operation Voltage Range,

It's a good accessory for your RC RC Car Truck Crawler Boat Robot and DIY model toy!

Specifications:

Brand:GXservo

Model: G80

Puise Width: 500μs-2500μs =180°/270°/360°

Operating Speed: (6.0V)0.16sec60°

Operating Speed: (7.4V)0.15sec60°

Operating Speed: (8.4V)0.14sec60°

Stall Torque(6.0V): 72kg.cm

Stall Torque(7.4V): 80kg.cm

Stall Torque(8.4V): 87kg.cm

Operating Voltage: 4.8V-8.4V

Gear Type: Steel

Motor: Coreless motor

Dead band: 2μs

Ball Bearing: 3BB

Working Frequence: 1520μs/330hz

Shell Materal: CNC aviation aluminium alloy

spline tooth? 15T

Control System: Customizable(PWM,RS485 ,TTL,CAN)

Dimensions: 65*30*58mm

Weight: 200g

Due to the different monitor and light effect, the actual color maybe a slight different from the picture color.
Please allow 1-3mm differs due to manual measurement.

2. Waterproof performance: IP67.

3. Precision metal steering gear.

4. Widely Use Digital Servo:The steering servo (Control Angle 180°) Compatible with 1/5, Scale Clawer Truck, Traxxas, scx10, RC Car / Robot / Boat and other remote control models.

Description:

1000KG Large torque Digital Waterproof servo,adopt Brushless motor,Compared with ordinary servo, the speed is much faster and the reaction is also fast,24V High Operation Voltage Range,

It's a good accessory for your RC RC Car Truck Crawler Boat Robot and DIY model toy!

Specifications:

Brand: GXservo

Model: GX931000BLS

Puise Width: 500μs-2500μs =180°/270°/360°

Operating Speed: (20V)0.45sec60°

Operating Speed: (24V)0.40sec60°

Stall Torque(20V): 600kg.cm

Stall Torque(24V): 800kg.cm

Operating Voltage: 20V-28V

Gear Type: Steel

Motor: Brushless motor

Ball Bearing: 2BB

Working Frequence: 1520μs/330hz

Dimensions: 132*55.3*100mm

Shell Materal: CNC aviation aluminium alloy

spline tooth?25T

Control System: Customizable(PWM,RS485 ,TTL,CAN)

Weight: 1.066kg

1. 6.0V-8.4V High voltage.High performance digital High Voltage Brushless.

2. Waterproof performance: IP67.

3. Precision metal steering gear.

4. Widely Use Digital Servo:The steering servo (Control Angle 180°) Compatible with 1/5,Scale Clawer Truck, Traxxas,

RC Car / Robot / Boat and other remote control models.

Description:

130KG Large torque Digital Waterproof servo,adopt Brushless motor,Compared with ordinary servo, the speed is much faster and the

reaction is also fast,6.0V ~8.4V High Operation Voltage Range,

It's a good accessory for your RC RC Car Truck Crawler Boat Robot and DIY model toy!

Specifications:

Brand: GXservo

Model: X130

Due to the different monitor and light effect, the actual color maybe a slight different from the picture color.
Please allow 1-3mm differs due to manual measurement.

Specifications

Quantity

1 pcs

Size

66x30x58mm

For Vehicle Type

Cars

Four-wheel Drive Attributes

Motors

Remote Control Peripherals/Devices

Servos

Upgrade Parts/Accessories

Gear

RC Parts & Accs

Servos

Material

Metal

Brand Name

GXservo

Origin

Mainland China

Recommend Age

12+y,14+y

Use

Vehicles & Remote Control Toys

Features:

1. 6.0V-8.4V High voltage.High performance digital High Voltage Brushless.

2. Waterproof performance: IP67.

3. Precision metal steering gear.

4. Widely Use Digital Servo:The steering servo (Control Angle 180°) Compatible with 1/5, Scale Clawer Truck, Traxxas,

scx10, RC Car / Robot / Boat and other remote control models.

Description:

120KG Large torque Digital Waterproof servo,adopt Brushless motor,Compared with ordinary servo, the speed is much faster and the

reaction is also fast,6.0V ~8.4V High Operation Voltage Range,

It's a good accessory for your RC RC Car Truck Crawler Boat Robot and DIY model toy!

Specifications:

Brand: GXservo

Model: X120

Puise Width: 500μs-2500μs =180°/270°/360°

Operating Speed: (6.0V)0.16sec60°

Operating Speed: (7.4V)0.14sec60°

Operating Speed: (8.4V)0.13sec60°

Stall Torque(6.0V): 110kg.cm

Stall Torque(7.4V): 120kg.cm

Stall Torque(8.4V): 135kg.cm

Operating Voltage: 6.0V-8.4V

Gear Type: Steel

Motor: Brushless motor

Dead band: 2μs

Ball Bearing: 3BB

Working Frequence: 1520μs/330hz

Shell Materal: CNC aviation aluminium alloy

spline tooth? 15T

Control System: Customizable(PWM,RS485 ,TTL,CAN)

Dimensions: 65*30*58mm

Weight: 210g

Due to the different monitor and light effect, the actual color maybe a slight different from the picture color.
Please allow 1-3mm differs due to manual measurement.

Specifications

Quantity

1 pcs

Size

66*30*58mm

Model Number

X120

For Vehicle Type

Cars

Four-wheel Drive Attributes

Assemblage

Remote Control Peripherals/Devices

Servos

Upgrade Parts/Accessories

Gear

RC Parts & Accs

Servos

Material

Metal

Brand Name

GXservo

Origin

Mainland China

Recommend Age

12+y

Use

Vehicles & Remote Control Toys

Certification

CE

2. Waterproof performance: IP67.

3. Precision metal steering gear.

4. Widely Use Digital Servo:The steering servo (Control Angle 180°) Compatible with 1/5, Scale Clawer Truck, Traxxas, RC Car / Robot / Boat and other remote control models.

Description:

100KG Large torque Digital Waterproof servo,adopt Coreless motor,Compared with ordinary servo, the speed is much faster and the reaction is also fast,6.0V ~8.4V High Operation Voltage Range. It's a good accessory for your RC RC Car Truck Crawler Boat Robot and DIY model toy!

Specifications:

Brand: GXservo

Due to the different monitor and light effect, the actual color maybe a slight different from the picture color.
Please allow 1-3mm differs due to manual measurement.

Model: G100

Puise Width: 500μs-2500μs =180°/270°/360°

Operating Speed: (6.0V)0.19sec60°

Operating Speed: (7.4V)0.17sec60°

Operating Speed: (8.4V)0.16sec60°

Stall Torque(6.0V): 90kg.cm

Stall Torque(7.4V): 100kg.cm

Stall Torque(8.4V): 110kg.cm

Operating Voltage: 4.8V-8.4V

Gear Type: Steel

Motor: Coreless motor

Dead band: 2μs

Ball Bearing: 3BB

Working Frequence: 1520μs/333hz

Shell Materal: CNC aviation aluminium alloy

spline tooth? 15T

Control System: Customizable(PWM,RS485 ,TTL,CAN)

Dimensions: 65*30*58mm

Weight: 200g
